Anyconnect Debug

Setting up communications between an ASA and a radius server can be tricky, because it's hard to know what attributes the radius server is sending back and are being applied to a user session. One method is to use wireshark to capture the communications between the ASA and radius server. Another is to enable debugging on the ASA with debug dap trace. An easier way is to just have the attributes printed out on the end-user device when they log in.

The dynamic access policy feature of the ASA will let you input Lua functions to get this information. Open ASDM and go to

  • Configuration
  • Remote Access VPN
  • Network (Client) Access
  • Dynamic Access Policies
  • Click Add
  • Policy Name: debug
  • Priority: 1 (or whatever works in your environment)
  • In the Selection Criteria area, click Advanced
  • Make sure AND is selected. In the Logical Expressions box, enter:
  • Click OK to close the Add Dynamic Access Policy window, then click Apply

Now, if you log in to AnyConnect on a device, you'll notice that a dropdown message box appears and shows you the values of the AV pairs.

You might want to be able to toggle the display of the debug message from a freeradius server. That will allow you to turn it on when a user calls in and reports problems and you need to know what settings are being applied to their account.

  • On the freeradius server, change their user record and add Reply-Message = 'debug_print'. Note that you could use any attribute you want, but I know that Reply-Message does work.
  • Back in ASDM, go to the debug policy you created earlier and change it so that it only fires when Reply-Message = 'debug_print'
  • OK and Apply

Introduction

This document describes how to configure Security Assertion Markup Language (SAML) with a focus on Adaptive Security Appliance (ASA) AnyConnect through Microsoft Azure MFA.

Prerequisites

Requirements

Cisco recommends that you have knowledge of these topics:

  • Basic knowledge of RA VPN configuration on ASA.
  • Basic knowledge of SAML and Microsoft Azure.
  • AnyConnect Licenses enabled (APEX or VPN-Only).

Components Used

The information in this document is based on these software and hardware versions:

  • A Microsoft Azure AD subscription.
  • Cisco ASA 9.7+ and Anyconnect 4.6+
  • Working AnyConnect VPN profile

The information in this document was created from the devices in a specific lab environment. All of the devices used in this document started with a cleared (default) configuration. If your network is live, ensure that you understand the potential impact of any command.

Background Information

SAML is an XML-based framework for exchanging authentication and authorization data between security domains. It creates a circle of trust between the user, a Service Provider (SP), and an Identity Provider (IdP) which allows the user to sign in a single time for multiple services. Microsoft Azure MFA seamlessly integrates with Cisco ASA VPN appliance to provide additional security for the Cisco AnyConnect VPN logins.

SAML Components

Metadata: It is an XML based document that ensures a secure transaction between an IdP and an SP. It allows the IdP and SP to negotiate agreements.

Roles supported by the devices (IdP, SP)

A device may support more than one role and could contain values for both an SP and an IdP. Under the EntityDescriptor field is an IDPSSODescriptor if the information contained is for a Single Sign-On IdP or a SPSSODescriptor if the information contained is for a Single Sign-On SP. This is important since the correct values must be taken from the appropriate sections in order to set up SAML successfully.

Entity ID: This field is a unique identifier for an SP or an IdP. A single device might have several services and can use different Entity IDs to differentiate them. For example, ASA has different Entity IDs for different tunnel-groups that need to be authenticated. An IdP authenticating each tunnel-group has a separate Entity ID entries for each tunnel-group in order to accurately identify those services.

ASA can support multiple IdPs and has a separate entity ID for each IdP to differentiate them. If either side receives a message from a device that does not contain an entity ID that has been previously configured, the device likely drops this message, and SAML authentication fails. The Entity ID can be found within the EntityDescriptor field beside entityID.

Service URLs: These define the URL to a SAML service provided by the SP or IdP. For IdPs, this is most commonly the Single Logout Service and Single Sign-On Service. For SPs, this is commonly the Assertion Consumer Service and the Single Logout Service.

The Single Sign-On Service URL found in the IdP metadata is used by the SP to redirect the user to the IdP for authentication. If this value is incorrectly configured, the IdP does not receive or is unable to successfully process the Authentication request sent by the SP.

The Assertion Consumer Service URL found in the SP metadata is used by the IdP to redirect the user back to the SP and provide information about the user's authentication attempt. If this is configured incorrectly, the SP does not receive the assertion (the response) or is unable to successfully process it.

The Single Logout Service URL can be found on both the SP and the IdP. It is used to facilitate logging out of all SSO services from the SP and is optional on the ASA. When the SLO service URL from the IdP metadata is configured on the SP, when the user logs out of the service on the SP, the SP sends the request to the IdP. Once the IdP has successfully logged the user out of the services, it redirects the user back to the SP using the SLO service URL found within the SP’s metadata.

SAML Bindings for Service URLs: Bindings are the method the SP uses to uses to transfer information to the IdP and vice versa for services. This includes HTTP Redirect, HTTP POST, and Artifact. Each method has a different way of transferring data. The binding method supported by the service is included within the definition of that services. For example: SingleSignOnService Binding='urn:oasis:names:tc:SAML:2.0:bindings:HTTP-Redirect' Location='https://saml.example.com/simplesaml/saml2/idp/SSOService.php'/ >. The ASA does not support the Artifact binding. ASA always uses the HTTP Redirect method for SAML authentication requests, so it is important to choose the SSO Service URL that uses the HTTP Redirect binding so that the IdP expects this.

Certificates for Signature and Encryption Operations

To provide confidentiality and integrity for the messages sent between the SP and the IdP, SAML includes the ability to encrypt and sign the data. The certificate used to encrypt and/or sign the data can be included within the metadata so that the receiving end can verify the SAML message and ensure that it comes from the expected source. The certificates used for signing and encryption can be found within the metadata under KeyDescriptor use='signing' and KeyDescriptor use='encryption', respectfully, then X509Certificate. The ASA does not support encrypting SAML messages.

Network Diagram

Configure

Add Cisco AnyConnect from the Microsoft App Gallery

Step 1. Log in to Azure Portal and select Azure Active Directory.

Step 2. As shown in this image, select Enterprise Applications.

Cisco Anyconnect Log File Location

Step 3. Now select New Application, as shown in this image.

Step 4. In the Add from the gallery section, type AnyConnect in the search box, select Cisco AnyConnect from the results panel, and then add the app.

Step 5. Select the Single Sign-on menu item, as shown in this image.

Step 6. Select SAML, as shown in the image.


Step 7. Edit Section 1 with these details.

Step 8. In the SAML Signing Certificate section, select Download to download the certificate file and save it on your computer.

Step 9. Note this, it is required for ASA configuration.

  • Azure AD Identifier - This is the saml idp in our VPN configuration.
  • Login URL - This is the URL sign-in.
  • Logout URL - This is the URL sign-out.

Assign Azure AD User to the App

In this section, Test1 is enabled to use Azure single sign-on, as you grant access to the Cisco AnyConnect app.

Anyconnect

Step 1. In the app's overview page, select Users and groups and then Add user.

Step 2. Select Users and groups in the Add Assignment dialog.

Step 3. In the Add Assignment dialog, click the Assign button.

Configure ASA for SAML via CLI

Step 1. Create a Trustpoint and import our SAML cert.

Anyconnect Debug Tool

Step 2. These commands provision your SAML IdP.

Step 3. Apply SAML Authentication to a VPN Tunnel Configuration.

Note: If you make changes to the IdP config you need to remove the saml identity-provider config from your Tunnel Group and re-apply it for the changes to become effective.

Verify

Test AnyConnect with SAML Auth

Step 1. Connect to your VPN URL and input your login Azure AD details.

Step 2. Approve sign-in request.

Step 3. AnyConnect is Connected.

Common Issues

Entity ID Mismatch

Debug Example:

[SAML] consume_assertion: The identifier of a provider is unknown to #LassoServer. In order to register a provider in a #LassoServer object, you must use the methods lasso_server_add_provider() or lasso_server_add_provider_from_buffer().

Problem: Generally means that saml idp [entityID] command under the ASA's webvpn configuration does not match the IdP Entity ID found in the IdP’s metadata.

Solution: Check the entity ID of the IdP’s metadata file and change the saml idp [entity id] command to match this.

Time Mismatch

Debug Example:

[SAML] NotBefore:2017-09-05T23:59:01.896Z NotOnOrAfter:2017-09-06T00:59:01.896Z timeout: 0

[SAML] consume_assertion: assertion is expired or not valid

Problem 1. ASA time not synced with IdP’s time.

Solution 1. Configure ASA with the same NTP server used by IdP.

Problem 2. The assertion is not valid between the specified time.

Solution 2. Modify the timeout value configured on the ASA.

Wrong IdP Signing Certificate Used

Debug Example:

[Lasso] func=xmlSecOpenSSLEvpSignatureVerify:file=signatures.c:line=493:obj=rsa-sha1:subj=EVP_VerifyFinal:error=18:data do not match:signature do not match

File

[SAML] consume_assertion: The profile cannot verify a signature on the message

Problem: ASA not able to verify the message signed by the IdP or there is no signature for the ASA to verify.

Solution: Check the IdP signing certificate installed on the ASA to make sure it matches what is sent by the IdP. If this is confirmed, make sure that the signature is included in the SAML response.

Invalid Assertion Audience

Debug Example:

[SAML] consume_assertion: assertion audience is invalid

Problem: IdP is defining the incorrect audience.

Solution: Correct the Audience configuration on the IdP. It should match the ASA’s Entity ID.

Wrong URL for Assertion Consumer Service

Example Debug: Unable to receive any debugs after the initial authentication request is sent. The user is able to enter credentials at IdP but IdP does not redirect to ASA.

Problem: IdP is configured for the wrong Assertion Consumer Service URL.

Solution(s): Check base URL in configuration and make sure it is correct. Check ASA metadata with show to make sure that the Assertion Consumer Service URL is correct. In order to test it, browse it, If both are correct on the ASA, check the IdP to make sure that the URL is correct.

SAML Configuration Changes Not Taking Effect

Cisco Anyconnect Log File

Example: After a single sign-on URL is modified or changed, the SP certificate, SAML still does not work and sends previous configurations.

Problem: ASA needs to regenerate it's metadata when there is a configuration change that affects it. It does not do this automatically.

Solution: After making changes, under the affected tunnel-group remove and re-apply the saml idp [entity-id] command.

Troubleshoot

Most SAML troubleshoots involve a misconfiguration that can be found when the SAML configuration is checked or debugs are run. debug webvpn saml 255 can be used to troubleshoot most issues, however in scenarios where this debug does not provide useful information, additional debugs can be run:

Anyconnect Debug Mac
